Horizontal wood blocking is installed across vertical studs within the stud wall framing on the furniture side. Three rows of blocking are spaced vertically with measurements of two feet six and a half inches, one foot six inches, and one foot six inches from the base deck. All locations must be verified prior to installing blocking.
2' - 6 1/2" 1' - 6" 1' - 6" NOTES: 1. VERIFY ALL LOCATIONS PRIOR TO INSTALLING BLOCKING STUD WALL - FURNITURE SIDE BLOCKING, TYP. DECK
