An existing industrial mechanical arrangement features a 16-inch combustion air header and associated fuel gas piping supported by structural framing. A demolition note directs the removal of natural gas, landfill gas, and fuel gas piping along with all ancillary components. The overhead runs interface with structural steel framing and supports within the mechanical space.
REMOVE NG, LFG, FG PIPING AND ANCILLARY COMPONENTS ’ / ir ffl iMii' / r t f i a m <£> 16" COMBUSTION AIR HEADER
