A lead-lined metal frame is set within a partition framed with twenty-two gauge minimum metal track studs and gypsum board. Lead lining continuous within the partition returns into the frame assembly to maintain radiation shielding continuity. An applied glazing stop secures the lead glass, and perimeter sealant is applied to match the frame paint color.
LEAD LEAD GLASS GYP BOARD LEAD SEALANT AT PERIMETER OF FRAME TO MATCH FRAME PAINT COLOR APPLIED GLAZING STOP 22 GA MIN MTL TRACK - FRAME PER DETAILS ON A3.04 PARTITION HEAD AND FRAMING DETAILS (USE AT MTL STUDS AT JAMB CONDITIONS) INSIDE OUTSIDE
