This millwork plan detail shows a custom cabinetry corner assembly with welded and ground smooth joints at all breaks per elevation. The substrate is finished to wrap the visible end, with the visible face of blocking aligned to match the cabinet face. European spring hinges with soft close mechanisms are installed with necessary backing blocking. Dimensions indicate a one-and-a-half-inch reveal aligning with adjacent components.
EUROPEAN SPRING HINGES WITH SOFT CLOSE, TYP. 1 1/2" 1/2" WELD & GRIND SMOOTH, TYP @ ALL BREAKS PER ELEVATION FINISH TO WRAP VISIBLE END OF SUBSTRATE VISIBLE FACE OF BLOCKING TO MATCH CABINET FACE BLOCKING, AS NECESSARY ALIGN
