A wood door with a wood veneer finish matches the adjacent wall panels and is supported on a Norton Rixson pivot hinge above a concrete slab with sports flooring. The wall assembly consists of three-quarter-inch plywood panels with veneer mounted on one-and-a-quarter-inch blocking using Z-clips per the manufacturer's requirements. Type 2 backing is installed behind the panel system, and a solid wood wall base sits above the sports flooring.
DOOR WITH WOOD VENEER FINISH TO MATCH WALL PANELS NORTON RIXSON PIVOT JAMB CONCRETE SLAB; SSD SPORTS FLOORING; SEE FINISH SCHEDULE PARTITION PER SCHEDULE 3/4" PLYWOOD PANEL W/ VENEER 1 1/4" BLOCKING SOLID WOOD WALL BASE; SEE FINISH SCHEDULE TYPE 2 BACKING; SEE SPORTS FLOORING; SEE FINISH SCHEDULE Z-CLIP PER MANUFACTURER'S REQUIREMENTS 2/A9.20
