A-BM8TR — T221 - Custom Rosette

Architectural · A-BM8TR

T221 - Custom Rosette

Scale: SCALE: 6" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

EIFS / Plaster / Stucco Gypsum / Drywall

Elements

Ceilings Millwork / Casework

Text on the drawing

R 7 5/8" CL CL DESIGN BASED ON FABER ORNAMENTAL PLASTERING CORP PART NUMBER CM-036 FOR MOUNTING SECTION DETAIL SEE A1/A-662
