Text on the drawing
UTILITY BLDG MAIN LEVEL 99'-0" 05.44 06.54 03.11 TOP OF SILL PLATE 109'-9" U-501 D3 U-503 A1 CHILLER LEVEL 97'-6" U-502 A4 TOP OF MASONRY WALL 107'-0" 16' 8'
