This wall and roof intersection detail for a drive-through canopy features laminated decking and sheathing fastened to structural steel framing. The roof assembly includes tapered insulation, a pneumatic tube, and a framed head track with a deflection gap filled with sealant and compressible backer rod. An aluminum sub-frame system supports exterior rain screen panels with a three-quarter inch vent gap at the laminated decking. The vertical wall assembly incorporates foamed-in-place insulation, a weather-resistive barrier, cavity drainage mesh, and metal counter flashing above the canopy roof.
2ND FL. 440' - 7 3/4" D T.O. SHELF ANGLE 2' - 2 3/4" FOAMED IN PLACE INSULATION. 2" MIN. TAPERED INSULATION A7.34 1 SIM METAL COUNTER FLASHING TWF. LAP WRB CAVITY DRAINAGE MESH (3) COURSES HIGH WRB. LAP TWF. WRB. LAP TWF. EW5 EW5 SAM FLASHING ALU SUB-FRAME SYSTEM VENT CLOSURE FORMED HORIZONTAL SUB FRAMING ALU SUB-FRAME RAIN SCREEN PANEL SEALANT AND COMPRESSIBLE BACKER ROD. GAP TO MATCH REQUIRED DEFLECTION 3/4" VENT GAP TO LAMINATED DECKING PNEUMATIC TUBE. LOCATION T.B.D. FRAMING HEAD TRACK LAMINATED DECKING AND SHEATHING. FASTENED TO ANGLE PER STRUCTURAL
