A continuous hardwood trim with an eased edge details the bench back, featuring wood veneer over three-quarter-inch plywood on typical framing. A filler panel with wood veneer sits adjacent to library shelving. The assembly interfaces with an exterior curtain wall, referenced to exterior detailing drawings.
CONTINUOUS HARD WOOD TRIM WITH EASED EDGE +/- 2 1/4" WOOD VENEER O/ 3/4" PLYWOOD O/ FRAMING, TYP CURTAIN WALL; SEE EXTERIOR DETAILING CONTINUOUS HARDWOOD TRIM WITH EASED EDGE AT BENCH BACK FILLER PANEL W/ WOOD VENEER LIBRARY SHELVING
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
