A fire sprinkler pipe and head are suspended beneath an Epic roof deck, utilizing a sixteen gauge steel plate secured with self-drilling fasteners. A removable cap covers the underside opening, which coordinates with Epic Metals and the general contractor for gym space integration. Five-eighths-inch DensDeck sits above the metal deck beneath six inches of rigid insulation. Batt insulation fills the profile of the roof deck flutes.
