A strut-channel mounts overhead and secures to the structure with connecting hardware. An eyebolts attaches to the channel, suspending a wire cable or carabiner. A second eyebolts connects the lower end of the cable to a connector bracket. The connector bracket holds the fabric diffuser support rail, which receives the fabric support tab from the fabric diffuser.
STRUT-CHANNEL RE: ARCH DWG FABRIC DIFFUSER FABRIC DIFFUSER SUPPORT RAIL (PROVIDED BY THE FABRIC DIFFUSER MANUFACTER) CONNECTOR BRACKET EYEBOLT EYEBOLT WIRE CABLE OR CARABINER STRUT-CHANNEL CONNECTING HARDWARE FABRIC SUPPORT TAB (PART OF THE FABRIC DIFFUSER) 1
