A continuous bottom track is anchored to a concrete floor slab using Hilti X-DNI shot-pins measuring 0.145 inch in diameter with a 1-inch embedment spaced at 16 inches on center per ICC-ES ESR 1663. Bearing studs are fastened to the bottom track with one number 8 screw at each flange on each stud. Each side of the wall is finished with one layer of 5/8-inch Type X gypsum board fastened with number 8 screws at 6 inches on center. Fire caulking is applied to both sides of the wall at the slab interface.
C FRAMED WALL @ BASE. CONT BOTT TRACK PER WALL FRAMING TABLE HILTI "X-DNI" SHOT-PINS (0.145 DIA x 1" EMBED) PER ICC-ES ESR 1663 @ 16" O.C. (1) #8 SCREW EA FLANGE @ EA STUD BEARING STUD SECTION. SEE TABLE AND NOTES (1) LAYER 5/8" TYPE X GYP BD EA SIDE OF WALL w/ #8 SCREWS @ 6" O.C. FIRE CAULKING. SEE 1/AD2.3 & 1/AD2.4 , BO SIDES OF WALL CONCRETE FLOOR SLAB
