An interior aluminum storefront door frame connects to a matching aluminum window system at the jamb. The door assembly is installed per the door schedule with a dimension point established on centerline. The aluminum window system framing attaches per manufacturer requirements.
ALUMINUM WINDOW SYSTEM ATTACH PER MANUFACTURES REQUIREMENTS DIM. POINT DOOR PER DOOR SCHEDULE EQ EQ 3" = 1'-0" 2-A8.61 18 INT ALUM SF DOOR @ JAMB
