An exterior storefront door jamb detail showing the connection between the door frame and the adjacent wall construction. The assembly incorporates a door jamb flat subframe and a door stop, with dimensions referenced from architectural plans. An insulating glass unit is set with a glass stop and gasket per finish. A door hinge is positioned at the frame interface, aligning with the edge of the wall and flashing below.
STOREFRONT DOOR PER SCHEDULE DOOR JAMB FLAT SUBFRAME DOOR STOP GLASS STOP W/ GASKET INSULATING GLASS UNIT PER FINISH DOOR HINGE EXTERIOR INTERIOR DIM. RE: PLANS EDGE OF WALL BELOW EDGE OF FLASHING BELOW PER MANUFACTURER
