Data rack posts are centered on the data cabinet abutment with equal spacing maintained between adjacent data cabinets. The cold aisle data cabinet anchorage is installed according to manufacturer recommendations and structural approval. A clear dimension of six feet zero inches separates the data cabinets.
COLD AISLE DATA CABINET ANCHORAGE (BY MANUFACTURER RECOMMENDATION AND STRUCTURAL APPROVAL) DATA RACK POST CENTERED ON DATA CABINET ABUTTMENT EQ EQ CLEAR BETWEEN DATA CABINETS 6' - 0"
