Architectural · A-BAQR5

Floor Plan - Level 3

Scale: 1/2" = 1'-0"
Units: imperial
Sheet: A-450
Discipline: Architectural

Materials

Stone

Elements

Floors / Slabs

Text on the drawing

1 A 2 1 A-320 FILL WITH 2" DIA RIVER ROCK, BLACK, TYP.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
