A W24 beam and a W16 beam with a coped flange frame into the web of an HSS column along gridline G. A bent full-depth shear plate connects the beams to the column web, with a one-inch clearance maintained between framing elements. The connection utilizes bolts and references details on sheets S5.41 and S5.31.
