An aluminum curtain wall mullion integrates with 1-5/16-inch glazing units and extruded aluminum horizontal and vertical fins. The assembly features precise angular alignment with 44.49-degree, 45-degree, 89-degree, and 90-degree framing geometries. The 6-1/2-inch dimensioned profile ties the exterior fins directly to the structural mullion framing.
1 5/16" GLAZING UNIT GLAZING UNIT ALUM HORIZONTAL FIN ALUM HORIZONTAL FIN ALUM CURTAIN WALL MULLION ALUM VERTICAL FIN 3" 6 1/2" 89° 44.49° 44.49° 45° 90° 1 5/16" 6 1/2"
