This millwork assembly consists of three horizontal tiers supported by vertical dividers. The horizontal surfaces are finished with PLAM-5 plastic laminate, while the vertical supports are designated as WD-1.2 typical. The base tier sits on leveling feet as needed above the line of finish floor. The assembly features a total height of 1'-4 1/4" for the top tier and 1'-2 1/2" for the middle tier, with a 4 3/4" base height.
