A-B6WNW — Plan Detail Room 159

Architectural · A-B6WNW

Plan Detail Room 159

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Floors / Slabs Partitions Walls

Text on the drawing

5/8" GYPSUM BOARD 3 5/8" METAL STUD 5/8" PLYWOOD ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS WALL ASSEMBLY, RE: FLOOR PLANS
