Cabinet interiors anchor to a metal stud wall through concealed metal backing using number twelve Hilti Kwik Flex screws spaced at sixteen inches on center. A finish plug matching the cabinet interior finish conceals each fastener location. The assembly ties into the gypsum board lined stud wall with optional direct attachment to the center of each vertical stud at twenty-four inches on center through pre-drilled screw holes.
CABINET INTERIOR METAL BACKING PER 2/A9.10 #12 HILTI KWIK FLEX SCREWS AT 16" O.C.(ICC 4780) @ 16" O.C. FINISH PLUG TO MATCH CABINET INTERIOR FINISH STUD WALL GYP. BOARD OPTIONAL ATTACHMENT: DIRECT TO CENTER OF EACH VERT. STUDS AT 24" O.C. W/ PRE-DRILLED HOLES FOR SCREWS
