A roof framing section is supported by steel structural members with an insulated ceiling assembly below. The concrete roof slab spans across the framing, terminating at a raised edge condition near grid line 7.1. Grid line markers 6.8, 7, and 7.1 provide spatial reference across the structural layout.
