This plan detail shows a hollow metal frame intersecting a gypsum board partition assembly. The hollow metal jamb is secured with jamb anchors and spot grouted in place. Continuous steel J-runners terminate the partition framing against the frame profile. Layers of gypsum board finish both sides of the partition, stopping with a half-inch clearance at the frame return. Partition construction and varying conditions are determined by the architectural partition type schedule.
VARIES 2" 5/8" SEE PARTITION TYPE FOR VARYING CONDITIONS SPOT GROUT 08 1113 HM FRAME 09 2900 GYPSUM BOARD 09 2116 CONTINUOUS STEEL J-RUNNER 08 1113 JAMB ANCHOR 1 15/16" 1/2" 1/2" SPOT GROUT
