This plan detail shows an interior switchback stair configuration with eleven treads at twelve inches spanning ten feet and one inch. A four-foot-six-inch landing return connects the parallel runs, bounded by perimeter walls. A contrasting color stripe per IBC section 504.4.1 is called out at the stair nosing. Dimensions indicate an overall stair width of fourteen feet and seven inches.
