The assembly features folded aluminum panels with hidden fastening and rigid insulation, supported by a vertical steel tube parapet frame beyond. An aluminum tuning fork mullion integrates into the exterior wall system adjacent to the structural steel framing. Dimensions indicate specific offsets including a minimum three foot six inch parapet height and typical two foot three inch modular spacing.
ALUMINUM PANEL, FOLDED BACK, HIDDEN FASTENING WITH RIGID INSULATION VERTICAL STEEL TUBE PARAPET SUPPORT BEYOND ALUMINIUM TUNING FORK MULLION 6" 3" 3" 2" 4" min 3' 6" TYP. 2' 3"
