Architectural · A-AXCRE

Living Wall Bracket and End Panel Connection

Materials

Steel Metal (misc.)

Elements

Walls Facades / Cladding Connections / Plates

Connections

Bolted Connection

About this detail

An insulated metal panel abuts a half-inch stainless steel plate secured with stainless steel bolts, nuts, and nylon shoulder washers with a half-inch nylon spacer. A half-inch by five-inch aluminum vertical bar acts as the primary mounting member, tied to a half-inch by three-inch aluminum vertical bar with quarter-inch aluminum horizontal round bars at the front and rear of the lattice assembly.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
