An epoxy flooring system is installed over a concrete subfloor with a maximum slope of one-to-two at the transition edge. A Schluter Reno-U profile edges the epoxy flooring where it meets the adjacent sealed concrete flooring. Flooring transitions are maintained at no greater than one-half inch typical across the joint.
SLAB TOP OF SEALED CONCRETE FLOORING - SEE FINISH SCHEDULE CONCRETE SUB - FLOOR, SEE STRUCTURAL DRAWINGS EPOXY FLOORING - SEE FINISH SCHEDULE SCHLUTER RENO-U 1:2 MAX SLOPE FLOORING TRANSITIONS TO BE NO GREATER THAN 1/2" , TYP.
