An unpunched sixteen-gauge steel deflection track with two-and-a-half-inch deep legs fastens to the underside of a composite concrete deck running parallel. Powder-actuated fasteners measuring zero-point-one-five-seven inches by one inch anchor through the deck flute at a maximum of sixteen inches on center, complying with ICC ESR-twenty-two-sixty-nine. Wall studs are provided per plan and wall type, framed with two jamb studs and continuous bridging as mandated. Dimensions for the assembly are referenced per structural drawings.
0.157" x 1" P.D.F. @ FLUTE BEYOND @ 16" O.C. MAX (ICC ESR-2269). PROVIDE (2) @ JAMB STUDS WALL STUDS PER PLAN AND WALL TYPE COMPOSITE CONCRETE DECK. SEE STRUCTURAL UNPUNCHED 16GA 2.5" DEEP LEG DEFLECTION TRACK CONT. BRIDGING PER (MANDATORY) FOR DIMS SEE DETAIL:
