A hollow metal door frame head assembly is installed within a metal stud wall with gypsum board facing. Insulation fills the wall cavity and the door frame header. Joint sealant is applied at the junction between the gypsum board edge and the door frame flange. The door leaf is sized per the door schedule.
081113.HMF SEE DOOR SCHED 092900.GWB 072100.SB SEE WALL TYPES (6") 079200.JS 092216.T 092216.SS 2 3
