Diagonal braces connect to a vertical column and horizontal beam intersection using a half-inch connection plate welded with five-sixteenths welds typically. The assembly features centered work points with specific dimensional clearances of one inch and two inches typically. Fasteners secure the diagonal members to the gusset plates.
1" TYP 1" TYP 2" TYP 1 1/4" TYP 2" TYP 1/2" CONN. PL, TYP 5/16 TYP WP
