A cast-in-place concrete curb and gutter section rests on a compacted layer of select fill. The overall width of the concrete section measures twenty-four inches, with a total back-of-curb height of twelve inches and a gutter thickness of six inches. The gutter slopes downward to a seven-inch thickness at the face of the curb. A contraction joint is located near the middle of the concrete profile. The top back and face edges feature three-quarter-inch radii.
