An architectural detail showing a compression strut and suspended ceiling grid attached to the underside of a concrete deck and structural steel beam. The vertical compression member stabilizes the ceiling framing against lateral loads, tied back to the overhead floor structure. Suspension wires and lateral bracing components anchor directly into the concrete-filled metal deck and supporting steel framing elements.
A. CEILING GRID ATTACHMENT
