A wall corner is wrapped in wall carpet and protected at the outer edge by a black corner guard secured with screws. The finish maintains a typical three-eighths inch overhang aligned with a top cap above.
3/8" OVERHANG, TYP. BLACK CORNER GUARD ATTACHED WITH SCREWS WALL CARPET TOP CAP ABOVE
