Window sprinklers are positioned at the second floor elevation of 101 feet 6 inches to achieve a one-hour fire rating at the interior face of glazing.
SECOND FLOOR 101'-6" Ab WINDOW SPRINKLERS TO ACHIEVE 1 HOUR FIRE RATING AT THE INTERIOR FACE OF GLAZING
