A cast-in-place concrete wall supports hollow structural section horizontal posts at 10 feet on center maximum via metal angles and connection plates. A curved hollow structural section 4x4x1/4-inch horizontal tube serves as framing alongside curved metal bottom tracks and 4-inch metal studs spaced at 16 inches on center. The exterior features curved 5/8-inch gypsum board finished with continuous 1x3 hardwood clear members spaced at 4 feet on center, terminating above a 1/8-inch metal plate.
WP-01 HSS 4X4X1/4" HORIZONTAL TUBE,CURVED MTL BOTTOM TRACK, CURVED 5/8" GYP BD. 4" MTL STUDS @ 16" OC HSS 4X4X1/4" HORIZONTAL POST @ 10'-0" OC MAX CONT 1x3 HD WD CLEAR @ 4'-0" OC 1/2" 1/8" MTL PLATE METAL ANGLE HSS 4X4X1/4" HORIZONTAL POST @ 10'-0" OC MAX CIP CONC
