This accessible drinking fountain assembly features specific mounting heights and clearance dimensions for compliance. The spout outlet is located at a maximum of 36 inches above the finished floor, with a minimum 27-inch knee clearance below the unit. The top of the unit is positioned at 38 to 43 inches maximum from the floor. A minimum 48-inch clear floor space is required in front of the fixtures, with wall projections limited to a maximum of 4 inches. Side clearances measure 18 to 19 inches minimum from the wall, with adjacent partitions spaced to maintain unobstructed access.
