Two continuous number four reinforcing bars are installed in the upper third of the slab within the previous pour adjacent to the new dead end saw joint, terminating three inches from any intersecting joint. A spray bond breaker is applied along the face of the construction joint. Typical dowels are spaced at one foot on each side of the saw joint. The sawcut at the joint intersection is executed at full depth for the last two feet, ending one quarter inch prior to the intersection with no overcut allowed into the existing slab.
1) SPRAY BOND BREAKER ALONG FACE OF CONSTRUCTION JOINT. 2) SAWCUT AT JOINT INTERSECTION TO BE FULL DEPTH FOR THE LAST 2'-0". 3) END SAW CUT 1/4" PRIOR TO INTERSECTION. ABSOLUTELY NO OVERCUT INTO EXISTING SLAB. 2'-6" 1'-0" 1'-0" 2'-6" 2 - #4 CONTINUOUS BARS (UPPER 1/3 OF SLAB) TO BE INSTALLED IN PREVIOUS POUR ADJACENT TO NEW DEAD END SAW JOINT (TERMINATING 3" FROM ANY INTERSECTING JOINT). SAW JOINT TYPICAL DOWEL (SEE 1/DC1; UNLESS NOTED OTHERWISE) AT 1'-0" EACH SIDE OF SAW JOINT TYPICAL DEAD END SAW JOINT/ "T" JOINT 2 0'-3" 0'-3" ℄ 0'-1 1 2 " 0'-1 1 2 " 1'-0" CONSTRUCTION JOINT
