An elevator door frame is integrated into a partition wall framing system. The assembly consists of typical type X gypsum board over insulation and a one-inch gypsum liner panel. A twenty-five gauge J-track secures the gypsum liner panel at the header condition above the elevator door opening.
1" GYP LINER PANEL, TYP. INSULATION, TYP. TYPE 'X' GYPSUM BOARD, TYP. 1" GYP LINER PANEL, TYP. 25 GA J-TRACK, TYP. ELEVATOR DOOR FRAME, TYP. ELEVATOR DOOR DOOR OVER 7'-0" HIGH
