A structural and architectural interface for mounting a ships ladder to a concrete-filled metal deck assembly. A steel mounting bracket connects to the ladder and is bolted to a minimum three-sixteenths inch steel plate. The assembly anchors to the concrete slab and metal deck, which bears on a structural steel beam sized per structural drawings. A railing shown beyond aligns with the wall and ladder assembly per manufacturer specifications.
RAILING (BEYOND) WELD PLATE TO DECK PER STRUCT. ATTACHE PER LADDER MFR. MOUNTING BRACKET PER MFR. SEE WALL TYPES 055000.MSL 055000.SWA 033000.S 053100.FD 051200.B 3/16" PLATE STEEL MIN. SEE STRUCT.
