This suspended ceiling junction detail shows a ceiling tee terminating near a wall angle with no rigid attachment to the wall angles, maintaining a 3/8-inch minimum and 7/8-inch minimum clearance. A spacer bar is placed between all tees for alignment. Twelve-gauge hanger wires support the ceiling grid and may be installed vertically or sloped up to a maximum ratio of 1 in 6.
B.2 DETAIL @ TWO ADJACENT WALLS WITH NO ATTACHMENT TO WALL ANGLES 8" MAX. 3/8" MIN. 7/8" MIN. WALL ANGLE; ATTACH TO WALL. SPACER BAR BETWEEN ALL TEES 12 GA. HANGER WIRE; INSTALL EITHER SLOPED 1:6 MAX OR VERTICALLY. 1 IN 6 MAX.
