The roofing membrane extends up and over a foam backing rod, sealing the joint above a structural support. A two-inch fiberglass insulation filler fills the void beneath the metal deck profile. Fasteners secure the termination assembly through the deck into the underlying support.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
