Upper cabinet assembly featuring two adjustable shelves and a plastic laminate interior finish per elevation. The cabinet incorporates a fixed panel to the ceiling with faces aligned to the door, finished to match the cabinet and supported by blocking as required. An under-cabinet light is included where specified, with dimensions and clearances coordinated relative to the ceiling.
(2) ADJUSTABLE SHELVES FIXED PANEL TO CEILING, ALIGN FACE WITH FACE OF DOOR, FINISH TO MATCH CABINET BLOCKING AS REQUIRED TO AFFIX FRONT PANEL CEILING SEE INTERIOR ELEVATION SEE INTERIOR ELEVATION VARIES UNDER CABINET LIGHT, WHERE OCCURS SLOPED AT SIM. 1/2" 1/2" EQ EQ EQ PLASTIC LAMINATE INTERIOR FINISH PER ELEVATION 2"
