This isometric detail shows an end wall framing assembly with timber studs spaced at sixteen inches on center intersecting a wall pocket stud. The vertical studs connect to top and bottom C-channel tracks using two number ten screws at each connection. The layout provides structural support for the wall partition and forms a framed pocket junction.
C-CHANNEL TRACK 2X STUDS @ 16" O.C. WALL POCKET STUD CONNECT STUD TO CHANNEL WITH (2) #10 SCREWS (TYP) CONNECT STUD TO CHANNEL WITH (2) #10 SCREWS (TYP) C-CHANNEL TRACK CONNECT STUD TO CHANNEL WITH (2) #10 SCREWS (TYP) WALL POCKET STUD 2X STUDS @ 16" O.C. C-CHANNEL TRACK CONNECT STUD TO CHANNEL WITH (2) #10 SCREWS (TYP) C-CHANNEL TRACK
