An aluminum fence door post is secured with a 3/8-inch by 5-inch by 5-inch embedded base plate centered on the post and aligned with reinforcing U-bars. An aluminum door and cover panel connect to the post assembly via a full mortise hinge, positioned relative to an aluminum composite panel above and a concrete building curb. The top surface of the base plate aligns with the concrete at the door threshold.
1/4" 1 1/2" ALUM COVER PANEL ALUM DOOR BASE PLATE PER DETAIL 69/A5.6.1 - TOP SURFACE OF PLATE TO ALIGN WITH CONCRETE AT DOOR FULL MORTISE HINGE EDGE OF ALUMINUM COMPOSITE PANEL ABOVE TYP STRIP FOOTING PER DETAIL 56/A5.6.1 U-BARS ALIGN WITH BOLTS 3/8" X 5"X 5" EMBEDDED BASE PL, CENTERED ON FENCE POST, SEE DETAIL 56/A5.6.1 BUILDING CURB
