The steel channel stringer bears onto a six-inch thickened concrete slab and is secured using a half-inch diameter expansion bolt six inches deep. A two-by-two-by-three-eighths-inch steel angle, four inches long, is welded to the stringer. All cut and exposed ends feature a steel plate welded to the stringer and ground smooth. A six-inch deep sleeve accommodates the main vertical handrail post where required.
EQ. RISERS 2" = TREAD 1 1/4" 1' - 0" 6" THICKENED CONCRETE SLAB 1/2" DIA. EXPANSION BOLT 6" DEEP SLEEVE FOR HANDRAIL POST WHERE OCCURS STEEL PLATE AT ALL CUT AND EXPOSED ENDS, WELDED TO STRINGER, GRIND SMOOTH 2X2X3/8" BY 4" LONG STEEL ANGLE WELDED TO STRINGER STEEL CHANNEL STRINGER MAIN VERTICAL HANDRAIL POST WHERE OCCURS
