An insulated metal wall panel features a male and female interlocking joint secured to a horizontal support by a twelve gauge stainless steel hidden fastener clip. The clip is set in continuous butyl sealant and fastened with one quarter inch by fourteen hex head fasteners without a washer. Additional continuous butyl sealant is applied within the interlocking joint profile. Wall panel installation proceeds in the direction indicated.
MALE JOINT FEMALE JOINT HORIZONT SUPPORT (NOT BY KINGSPAN) 1/8" CONTINUOS BUTYL SEALANT CONTINUOS BUTYL SEALANT (OPTIONAL) 12 GA. STAINLESS STEEL HIDDEN FASTENER CLIP (1 PER PANEL, PER SUPPORT) SET CLIP IN BUTYL SEALANT 1/4" - 14 HEX HEAD FASTENERS WITHOUT WASHER WALL PANEL INSTALLATION DIRECTION
