An aluminum window system rests on a structural base with shims placed as required for leveling. The sill joint is sealed on both sides using backer rods and acoustic sealant. The assembly incorporates one-inch insulated glazing units as specified in the window schedule. A dimension point establishes the reference location for the four-and-a-half-inch frame width, aligning with the face of the jamb beyond.
BACKER ROD AND ACOUSTIC SEALANT, BOTH SIDES SHIM AS REQUIRED ALUMINUM WINDOW SYSTEM ATTACH PER MANUFACTURES REQUIREMENTS DIM. POINT 1" INSULATED GLAZING SEE SCHEDULE FOR TYPE FACE OF JAMB BEYOND 0'-4 1/2"
