A fourteen-gauge angle measuring four by four inches and one foot four inches long fastens to the underside of a concrete-filled metal deck. When anchored to concrete and metal deck, the angle secures with four total zero-point-one-five-seven-inch diameter Hilti X-U powder-driven fasteners with one and one-quarter-inch embedment. When attached to metal deck only, the angle secures with four number twelve sheet metal screws running parallel to the flutes. A stud kicker, sized and spaced per wall sections, connects to the clip angle using four number ten sheet metal screws.
AT CONC & METAL DECK: 0.157"Ø HILTI X-U PDA W/ 1 1/4" EMBED (4) TOTAL AT METAL DECK ONLY: (4) #12 SMS PARALLEL TO FLUTES 14 GA L4x4x1'-4" STUD KICKER, SIZE & SPACING PER WALL SECTIONS W/ (4) #10 SMS TO CLIP 3 1/2" 3" 3" 3" 3 1/2"
