An extruded aluminum glazing frame is tied into a scheduled partition wall with a three-eighth-inch sealant joint at the junction. The aluminum frame supports scheduled glazing units on either side of the partition intersection. Dimensions show a four-and-one-half-inch frame depth and a two-inch setback to the partition face.
4 1/2" 2" SCHEDULED PARTITION 3/8" SEALANT JOINT SCHEDULED GLAZING EXTRUDED ALUM. FRAME VARIES DSF
