An eight-inch digital display unit is mounted to a display support structure sized per structural engineering documents. A continuous manufacturer prefinished sheet metal closer panel with hemmed edges on all sides finishes the assembly and matches the display bezel.
8" DIGITAL DISPLAY UNIT DISPLAY SUPPORT STRUCTURE, REFER TO STRUCTURAL CONTINUOS MANUFACTURER PREFINISHED SHEET METAL CLOSER PANEL W/ HEMMED EDGES, ALL SIDES - TO MATCH DISPLAY BEZEL
